AVR SX460 FOR GENERATOR FREE SHIPPING 460 AUTOMATIC VOLTAGE REGULATOR

We supply  (Please view below series link)

Website:

AVR Series SX460 SX440 AS440 AS480 R230 R438 R448 SE350 UVR6 SR7 12V 24V Generator Battery Charger 4 Amp 10AGenerator ATS AMF Control

SX460,brushless type avr is a compatible replacement spare parts for Stamford Newage.

Description

In addition to regulating the alternator voltage,the avr circuitry includes under-speed and sensing loss protection features.Excitation power os derived directly from the generator terminals.

Positive voltage build up from residual level is ensured by the use of efficient semiconductors in the power circuitry of the avr/
The avr is linked with the main stator windings and the exciter field windings to provide closed loop control of the output voltage with load regulator of +/-1.0%.

In addition to being powered from the main stator,the avr also derives a sample voltage from the output windings for coltage control purposes.In response to this sample voltage,the avr controls the power fed to the exciter field,and hence the main field,to maintain the machine output voltage within the specified limits,compensating for load,speed,temperature and power factor of the Alternator.

Features

Voltage Regulation < ±1%

Soft Start Voltage Ramping

Sensing Voltage Loss Protection

120 or 240 VAC Sensing, Jumper Selectable

Under Frequency Roll Off Protection

With Under Frequency LED Indicator

Model NO.	AVR SX460
Sensing Input	Voltage 120(95~132) / 240(190~264) VAC 1 phase 2 wire jumper selectable Frequency 50/60 Hz jumper selectable
Output	Voltage Max. 90 VDC @ 207 VAC input Current Continuous 4A, Intermittent 10A for 10 sec. Resistance Min. 15 Ohm
Voltage Regulation	< ±1% (with 4% engine governing)
Voltage Build-up	Residual volts at AVR terminal > 5 VAC
Soft Start Ramp Time	2 sec.
External Volts Adjustment	±7% with 1 K Ohm 1 watt trimmer
Unit Power Dissipation	Max. 10 watt
Thermal Drift	0.05% per °C change in AVR ambient
Under Frequency Protection (Factory Setting)	Set point 95% Hz Slope 170% down to 30 Hz
Environment	Operating Temperature : -40~70 °C Storage Temperature : -40~85 °C Relative Humidity : Maximum 95% Vibration : 3.3G @ 100~2 KHz
	VOLT : Voltage Adjustment STAB : Stability Adjustment UFRO : UFRO Knee Point Set
Dimensions	135.0 (L) x 100.0 (W) x 45.0 (H) mm
Regulator Weight	243 g ±2%

Within 1 year,if any problem buyers can returns avr to exchange another new one,buyers are responsible for the shipping fees and customs duty.

Before returning please confirm the return address and the logistics method with us. After you give the items to the logistic company, please send us the tracking number. As soon as we receive the items, we will repair or exchange them ASAP.

Different avr models or versions will have different functions. Please read the product descriptions carefully and learn the functions supported before placing an order .

Pls confirm the address and your TEL number for delivery to against any mistake.

About the shipping way we will choose the best way to you.If you can't accept we choose the suit ship way please don't make the order for this product.We will choose the shipping way from:DHL,FedEx,UPS,TNT,EMS,ePacket,Aremax,139 express.
