24V/30A Reversible DC Motor Controller,PWM Controller,Four-Quadrant Regeneration Brake, Pulse-Width Mdulation Speed Controlling

TECHNICAL PARAMETERS

Output Voltage

DC12RT30BL       12V

DC24RT30BL       24V

DC36RT30BL       36V

DC48RT30BL       48V

Soft start time:      0.2-20S Soft stop time:      0.2-20S Analog control signal:    0-5V (wired to earth ground) Signal input impedance   more than 200K Speed accuracy:         1% Speed adjustable range:  100:1 Speed Ratio:        1:80 Ambient temperature:     0 Celsius degree - 50 Celsius degree Relative Humidity:    Below dew point Weight:

FEATURES

MMT-DC24RT30BL series dc drive is DC-4Q Regenerative & Braking Reversible , PWM series DC Drive, it has quickly dynamic response, smooth operating, works well and perfect functions.

Pulse Width Modulation  Motor runs quieter, with greater efficiency and less maintenance, longer life. Four Quadrant Regenerative Operation  Regenerative Braking    No contactors required. No electromechanical components to overheat or wear out.  ENABLE / BRAKE / DIRECTION TERMINALS    Choose a function by simply opening or closing a dry contact or through an open collector transistor.  Status LEDs Power and Fault LEDs provide a visual status of the drive. Forward and reverse can be set separately Output current can be set Braking current can be set Torque compensation function Standard analog control mode: Analog: 0-5V or potentiometer Over Temperature Protection    Drive will fold the output power back to prevent from overheating. Drive will fault if it still remains too hot
