10 pcs of Brass Flow Meter Balancing Valve flow sensor for hot water system Обустройство дома - купить

Купить 10 pcs of Brass Flow Meter Balancing Valve flow sensor for hot water system | Обустройство дома

This listing includes: 10 pcs of balancing valve flow meter

- Size: Inlet size: G3/4”   Outlet: Rp1/2”

- Dimension: 80.5x27mm

- Net weight: 160g

- Brass

Application:

Direct reading and balancing valve with visual flow indication. Correct balancing of circuits ensure optimum efficiency of the system and can therefore help reduce energy consumption. Balancing valves facilitate fast and accurate adjustment of flow rates through heating and air conditioning circuits. Fluids Water and proprietary additives used against corrosion and freezing, Heating water, Cooling water, Potable water.

Advantages:

Precise and quick balancing without diagrams, tables or measuring devices. Flow rate displayed directly in L/min.

Regulating valve with adjustment scale.

Regulating valve with isolating facility (rest leakage possible).

Can be installed in any position.

Connect range fitting to the system.

Feature:

1. Max. operating pressure:10bar (1Mpa)

2. Max operating temperature:110°C

3. Measurement range: 2-8L/min

4. Measuring accuracy: +/-10%

5. Working Medium: water, Non-corrosive liquid, gas

6. Pipe thread to ISO 228 (BSP, NPT) is OK

7. When the calibrated pressure is reached, the valve opens automatically and discharge atmosphere to protect whole system in safe caused by over pressure

8. Safety valves are typically used for controlling pressure on boilers in heating systems, on stored hot water cylinders in domestic hot water systems and in water systems generally.

9. The valve achieves the purpose of automatic exhaust, then valve can be automatically discharged water and then shut down automatically.

Installation:

This valve may be installed in vertical, horizontal or inclined position. Care about be taken in order to ensure that the arrow is pointing in the direction of the flow.
