BE2208 1400KV short Shaft Brushless Motor For Mini Multicopters RC Plane Helicopter



Specifications:



Item name:BE2208short shaft KV:1400KV Pull: 1060g Motor size: Φ28×26

 Battery: 2-5s Lipo



Specifications:
KV..............................................................................................................1400
Configu ration....................................................................................NP
Stator Diameter....................................................................................22mm
Stator Length..........................................................................................8mm
Shaft Diameter.......................................................................................3.17mm
Motor Dimensions(Dia.*Len)...............................................Φ28×26mm
Weight (g)...................................................................................................44g
No.of Cells(Lipo).....................................................................................2-4S
Max Continuous current(A)............................................................26A
Max Continuous Power(W)...........................................................384W



Item No.	NO LOAD			ON LOAD			LOAD TYPE
BE2208-13 (1400KV)	VOLTAGE	CURRENT	SPEED	CURRENT	Pull	Power	Battery/prop
	V	A	rpm	A	g	W
	7.4	0.4	7970	3.4	170	25.2	LiPo*2/6*5E
				9.6	340	71.0	LiPo*2/7*5E
				10.3	430	76.2	LiPo*2/8*4E
				12.1	530	89.5	LiPo*2/9*6E
	11.1	0.5	11930	6.3	380	69.9	LiPo*3/6*5E
				16.1	580	178.7	LiPo*3/7*5E
				17.1	730	189.8	LiPo*3/8*4E
				19	835	210.9	LiPo*3/9*6E
	14.8	0.5	15880	9.8	640	145.0	LiPo*4/6*5E
				22.1	780	327.1	LiPo*4/7*5E
				23.5	960	347.8	LiPo*4/8*4E
				26	1060	384.8	LiPo*4/9*6E
