1.5KW 3.7A 3phase 380VAC MPPT solar pump inverter with IP65 for 1HP 0.75KW water pump Full automatic operation



Product Overview





INTRODUCTION:



This high efficiency solar pump inverter is compatible with single phase or 3 phase induction Water Pump Motor. Dynamic VI maximum power point traking (MPPT). Directly transferring solar energy into load using, really high conversion efficiency.

It's suitable for centrifugal pump, axial-flow pump, mixed-flow pump, deep well pump, etc..

It can be applied to daily use (ground water), agricultural irrigation, foretry irrigation, desert control, pasture animal husbandry, etc..



FEARURE:



1. Compatible with 3-phase induction Water Pump Motor
2. Dynamic VI maximum power point tracking(MPPT)
3. Can be installed outside without water-proof box
4. Full automatic operation
5. High conversion efficiency (above 98%)
6. Complete protective functions
7. Protection degree IP65
8. Built-in GPRS receiving module (M2Moptional)
9. Soft start and variable-frequency function
10. CEISO approved
11. 2 years warranty





Tech parameter





Model	Input  voltage	MPPT  voltage	Rated  Input  Current	PV Power	Inverter  Output  Current	Inverter  Rated  Power	Pump   Rated  Power		Output  Voltage	LINK
	VDC	V	(A)	KW	Rated (A)	KW	HP	KW	VAC
PS750S	250-500	280-450	11	1.08	7	0.75	0.5	0.37	1PH 220	Click here
PS750S1			11	1.08	7	0.75	0.75	0.55		Click here
PS1000S			11	1.62	9	1	1	0.75		Click here
PS1500S			13	1.8	14	1.5	1.5	1.1		Click here
PS2200S			13	2.52	16	2.2	2	1.5		Click here
PS4000S			20	4.32	23	4	3	2.2		Click here
PS4000S1			20	5.04	23	4	4	3		Click here
PS750L	250-500	280-450	6	1.08	4.5	0.75	0.75	0.55	3PH 220	Click here
PS1500L			9	1.62	7	1.5	1	0.75		Click here
PS1500L1			9	1.8	7	1.5	1.5	1.1		Click here
PS2200L			13	2.52	10	2.2	2	1.5		Click here
PS4000L			20	4.32	16	4	3	2.2		Click here
PS4000L1			20	5.04	16	4	4	3		Click here
PS750H	450-750	480-600	4	1.5	2.5	0.75	0.75	0.55	3PH 380	Click here
PS1500H			5	1.5	3.7	1.5	1	0.75		Click here
PS1500H1			5	1.8	3.7	1.5	1.5	1.1		Click here
PS2200H			7	2.4	5	2.2	2	1.5		Click here
PS4000H			12	4.25	9	4	3	2.2		Click here
PS4000H1			12	4.5	9	4	4	3		Click here
PS5500H			17	8.5	13	5.5	5	3.7		Click here
PS5500H1			17	8.5	13	5.5	5.5	4		Click here
PS7500H			22	8.5	17	7.5	7.5	5.5		Click here
PS11KH			32	12.75	25	11	10	7.5		Click here
PS11KH1			32	12.75	25	11	12.5	9.2		Click here
PS15KH			41	16.8	32	15	15	11		Click here
PS15KH1			41	17.6	32	15	18.5	13		Click here
PS18KH			50	21	37	18	20	15		Click here



Product Details





Application





Centrifugal pump, axial-flow pump, mixed-flow pump and deep-well pump can be utilized.Applied to daily use (ground water), agricultural irrigation, forestry irrigation, desert control, pasture animal husbandry, water supply for islands, wastewater treatment engineering, and other water supply applications.



Animal Husbandry:





It includes pump, solar  controller, solar panel, and reservoir. This system adopts solar power pump to satisfy the water demand of animals and plants in pasture as well as desert control instead of grid, diesel generator and battery. The whole system is operated automatically, achieving the goals of free maintenance and energy efficiency. It is particularly applicable in inconvenient traffic areas without grid.
Application:Pasture, Forest Farm, Meadow, Livestock farm, Desert, etc.



Desert Control:





This system includes pump, solar  controller, solar panel, and reservoir. It adopts solar power pump to satisfy desert water supply for instead of grid, diesel generator and battery.
Application: desert water supply, desert control, desert irrigation, etc.



Irrigation:





This system is composed of pump, solar controller, solar panel and irrigation equipment. It mainly takes advantage of solar power driven pumps for water instead of diesel and grid irrigation system, which provides convenient installation, saves energy and improves the economic benefit, especially for electricity shortage areas.
Applications:farmland, orchard,  garden, etc.



Swimming Pool:





This system is mainly composed of pump, solar controller, solar panel, swimming pool and water recycling equipment.  Via making full use of solar power, it can reduce the cost of swimming pool and beautify the environment, which is applicable in unstable grid areas.
Application:Gymnasium, villa, hotel, holiday village, etc.







Factory

About us:



Xiamen MARSROCK Technologies Co., Ltd located in Xiamen is a high-tech company specialized in R&D, manufacture, marketing, and service of solar controller, Hybrid Inverter and outdoor cabinets. Including  solar pump controller, solar street lights controller, Home using solar controller, outdoor cabinet and Mini shelter for mobile site.We engaged in providing  our best solutions of solar street light, solar pump system, solar home using system and  outdoor cabinet for our customer.

We have a  team with professional background in solar power products and outdoor cabinet design,dedicating to be the one of best suppliers for solar power system in the world.
