WH2004L WINSTAR - Дисплей LCD символьный на 24 символа 2 строки встроенный контроллер IC ST7066 экран с белой подсветкой - купить

Купить WH2004L WINSTAR - Дисплей LCD символьный на 24 символа на 2 строки, встроенный контроллер IC ST7066, экран с белой подсветкой.

WH2004L WINSTAR 24 characters by 2 lines Character LCD display module which is built in with ST7066 controller IC. screen backlight

we system acquiescence will send WH2004L-TGH-GT#

►LCD Character Displays 20x4
►5x8 dots includes cursor
►Bulit-in controller (ST7066 or Equivalent)
►+5V power supply (Also available for +3V)
►Negative voltage optional for +3V power supply
►1/16 duty cycle
►LED can be driven by PIN1, PIN2, PIN15, PIN16 or A and K
►Interface : 6800, option SPI/I2C (RW1063 IC)

Winstar WH2004L is 24 characters by 2 lines Character LCD display module which is built in with ST7066 controller IC; its default interface is 6800 4/8-bit parallel.  These 20x4 LCD display modules are also available in SPI and I2C interface by using RW1063 controller IC. This type of module can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.  WH2004L is available in several different backlight colors including blue, green, yellow-green, amber, red and white LEDs. The LEDs can be driven by pin 1, pin 2, or pin 15 pin 16 or A/K.  There are different character fonts/texts available for ST7066 IC including English/Japanese, English/West European, English/Scandinavian European, or English/Cyrillic (Russian) as options.
