Engraving machine 2030 2 in 1 CNC Router /Engraving Drilling and Milling Machine

Introduction

This is a very good era,in the past we only can see the CNC machine equipment in factory, but now, the CNC equipment has been into our lives;

Whether you are a small or medium enterprises managers, project engineers, CNC enthusiast or artists, related students, there are something on this machine will attract you;

It can help you processing a lot of parts, whether you are modeling or home decoration or creative DIY.

It can help you intuitively to learn CNC knowledge. And testing learning outcomes in real time.

Warranty

More Precise Stepping Motor

Simple operation and installation

1 year machine part and 6 months electrical parts、stepping motor、spindle Free Warranty

MODEL	CNC 2030
Attribute	3axis LPT	3axis 2 in 1	4axis LPT	4axis 2 in 1
Axis	3axis	3axis	4axis	4axis
Interface	LPT	LPT+USB port	LPT port	LPT+USB port
Spindle Motor:	300W	300W	300W	300W
Weigh	24	25	28	29
Max. working stroke	XYZ=20030058mm
Acceptable material thickness	≤80mm
Rail type	X and Z axis to hard shaft diameter of 12 mm, Y axis is hard shaft diameter 16 mm; Three axis are M8 stainless steel screw, with double nut back to poor organization
Spindle motor	300W DC spindle , 0-11000r/min
Collet type	ER11,1/8"(3.175mm) Collet
Stepper motor and drive	57BYGH-2.4A,
Maximum operating speed	2500mm/min (Engraving speed :　300-2500mm/min)
Repeat positioning Accuracy	0.03mm
Communication interface	Only LPT or 2 in 1-Parallel port and USB port ( CNCUSBController )
Software Co patability	Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam)
Command code	G code/.nc/.ncc/.tab/.txt
Machine weight	26kg
With Rotation Axis (4th Axis) Description	Center height: H=50mm Reduction ratio 4:1 Stepping motor: 57-2.4A Weight: 4kg
