Bringsmart A3650 Brushless DC Motor 12V 24V Mini 3000rpm 6000rpm Reversed Built-in Driver High Speed Torque Обустройство дома - купить

Купить Bringsmart A3650 Brushless DC Motor 12V 24V Mini 3000rpm 6000rpm Reversed Built-in Driver High Speed Torque | Обустройство дома

1. Consignee   Please use a Full Name as the consignee, or cargo can't reach to you. Especially in Russian Federation. Thanks for understand.   All products were checked well before delivering, please placing order without concern.     2. Delivery   Usually we send out your order in 2-8 days after payment. we promise to refund or resend if you don't get parcel, but pls give also patience of waiting the parcel during the delivery date, for the parcel still on the way to you.   Any problem pls just contact us first.       Feature:   Voltage range: 6-24V   12V4000rpm, 24V8000rpm   Shaft Length: about 10mm   Low noise, Without plug, Forward and backward controlled, Long lifespan, Continuous working time above 30,000hrs.     Wiring   [Red] for positive power supply, positive and negative can not be wrong;   [Black] power supply is negative, positive and negative can not be wrong;   [White line] Reversing control line, When disconnected, a steering motor, Together with the black line then negative, motor commutation;   [Blue Line] PWM speed Cords, 0 ~ 5V PWM converter   [Yellow Line] FG signal line     Please note: Do not reverse the positive and negative poles, otherwise it will burn out the internal driver. If you burn the motor because of the wrong wiring, we cannot return or exchange goods. ​
