New Original Programmable Controller Module XC-E3AD4PT2DA-H PLC Analog AI3 AO2 4 Channels PT100 Обустройство дома - купить

Item

Analog current input(AD)

Temperature input

(PT)

Analog voltage output(DA)

Analog input

DC0~20mA,4~20mA

PT100

-

Range of temperature detect

-

-100~350°C

-

Max output range

DC0~40mA

-

-

Range of analog output

-

-

DC0~5V,0~10V

(External load resistance 2KΩ~1MΩ)

Range of digital input

-

-

10 bits(0~1023)

Range of digital output

14 bits(0~16383)

-1000~3500

-

Resolution

1/16383(14Bit); Converted data are stored in PLC(14Bit) in hex form

0.1°C

1/1023(10Bit); Converted data are stored in PLC in hex form(10Bit)

PID output value

0~K4095

-

Integrated accuracy

0.8%

±0.5°C

0.8%

Convert speed

20ms/1 channel

3ms/1 channel

Power for analog

DC24V±10%,100mA

Installation

Fixed with M3 strews or directly installed in DIN46277(35mm width) guide rail

External dimension

63mm×102mm×73.3mm

Model

Function

XC-E4AD

14Bit, 4 channels analog input, current/voltage selectable

XC-E4AD-H

14Bit, 4 channels analog input, current/voltage selectable

XC-E8AD

14Bit, 8 channels analog input, current/voltage selectable

XC-E8AD-H

14Bit, 8 channels analog input, current/voltage selectable

XC-E2DA

12Bit, 2 channels analog output, current/voltage selectable

XC-E2DA-H

12Bit, 2 channels analog output, current/voltage selectable

XC-E4DA

12Bit, 4 channels analog output, current/voltage selectable

XC-E4DA-H

12Bit, 4 channels analog output, current/voltage selectable

XC-E4AD2DA

12Bit, 4 channels analog input, 2 channels analog output

XC-E4AD2DA-H

12Bit, 4 channels analog input, 2 channels analog output

XC-E3AD4PT2DA

4 channels Pt100 temp sampling, 3 channels analog input, 2 channels analog output

XC-E2AD2PT2DA

2CH PT100 temperature input (0.01°C precision), support PID auto tune, separate PID parameters setting, CPU communication;2CH 16bits analogue input, (current/voltage selectable);2CH 10 bits analogue output

XC-E6PT

0-300°C, 6 channels Pt100 temp sampling, precision 0.2 degree

XC-E6PT-P

0-300°C, 6 channels Pt100 temp sampling, precision 0.2 degree, PID output

XC-E6PT-P-H

6CH Pt100 input, 6CH output, 2 group of PID parameters; temperature scope: -100~350°C, 0.1°C resolution;

XC-E6TCA-P

0-1000°C, 6 channels manifold thermocouple temp sampling, precision 0.1 degree, PID output, can sample temp in individual.

XC-E2AD2PT-BD

2 channels 12 Bit analog input, 2 channels Pt100 temp sampling extend card.(XC3-14 do not support.)

XC-E2AD2DA-BD

2 channels 14 bit analog input, 2 channels 10 bits analog output extend BD card.
