12 В/24 В 150 мм 6-дюймовый регулируемый ход максимальная тяга 3500N 770LBS нагрузка 5 - купить

Купить 12 В/24 В 150 мм 6-дюймовый регулируемый ход максимальная тяга 3500N 770LBS нагрузка 5

Purchase Notes:

Because we are factory direct sales, please note when ordering 4 requests to facilitate early arrangements

1, Stroke (linear actuator telescopic distance)

2, Voltage (linear actuator voltage environment 12v24v does not affect the thrust and speed)

3, Speed (you asked how much time to finish the stroke you need)

4, Thrust (you need this linear actuator to push the number of kilograms of items)

(Other special requirements can be individually linked to us, including the shape of the transformation, the transformation of key parts)

Product parameters:

Drive voltage: 12VDC Maximum Thrust: 350KG/3500N Minimum installation dimensions (fully retracted around in the middle of the distance between the two holes): L1= Stroke+120 mm Maximum installation dimensions (fully extended around the middle of the distance of the two holes): L = 2xS(stroke)+120mm Ambient temperature :-26  to +65 degree Protection class: IP 54 Built-in limit switches(When completed stroke, linear actuator automatically stops!) Low noise design, noise levels below 42 db Work rule: 10%. Loading rated thrust need 10% work rule. In 20 minutes, 2minutes work 18minutes rest.             If lower load can extend work time. Color: black     30MM/S   500N            25MM/S   700N 15MM/S   1500N     10MM/S   2500N 5MM/S     3000N         3MM/S     3500N

12V24V electric putter motor, putter two ends have a stroke limit switch, telescopic rod running in the end or to the top, will automatically stop.

The motor does not empty the burner.
The push rod is a DC motor drive, screw drive. The telescopic rod can only be stretched without rotation.
The motor is positive and negative. Such as positive extension, negative shrinkage. Change the direction of the rod can be changed.
Note: bracket and controller is the need to purchase another, need friends please contact us.

Product Features: promoting other objects to push, pull, up, down action

Applications: TV lift massage table, electric bed, medical chair, electric equipment, micro-devices.



The linear actuator is auxiliary driving device, widely used in medical, Medical bed, massage chair,   electric foot sofa,  fitness equipment,  care bed, window open, ELECTRIC furniture,household, machinery, metallurgy, mine, petroleum, chemical industry, transportation, lifting, transportation, construction, food and feed processing industry. Widly application in line, massage armchair, automobile, the ventilation window open, military, stage, textile, sewage treatment and other industries equipment.
