Купить 4000W 3 Zones Hot Air IR BGA Soldering Machine Station HT-R490 | Инструменты
4000W 3 Zones Hot Air IR BGA Soldering Machine Station HT-R490with CE Certification
2 zons for Hot air heating 800W + 1 zone for Infraed preheating 2400W
Accept PCB size MIN 10*10mm, MAX 350*400mm
Accept chips size Max 80x80mm
Note:
the 110V version rework station doesn't have built-in vacuum pump, we will send the FFQ939 manual vacuum pen in accessory box.
BGA Rework Station Technical Parameters
Basic Parameters | |
Heating | HR |
Dimension | L580mmx W560mmx H650mm |
Weight | 28kg |
Total weight | About 35 kg, vary with the differen need of the users |
Electrical Parameters | |
Power | 220V 110V AC |
Upper Heating | HR |
Size of upper (IR) | --------------- |
Consumption of upper (IR) | --------------- |
Nozzle of upper(HR) | 4pcs: 19x19, 29x29,34x34,37x37 mm |
Consumption of upper (HR) | 800W |
Bottom Heating | HR |
Nozzle of bottom(HR) | 1 pcs: 50x50 mm |
Consumption of bottom (HR) | 800W |
Bottom Preheat | IR |
Consumption of preheat (IR) | 2400W |
General power | 4KW |
Temperature Control | |
Control mode of Upper | Independent temperature control, high-precision closed-loop |
Control mode of Bottom | Independent temperature control, high-precision closed-loop |
Rework Function | |
SMD | Suit for welding, remove or repair packaged devices |
Size of applicable chips | ≤80mm x80 mm |
Size of applicable PCB | MIN 10mm*10mm MAX 350mm*400mm |
BGA Rework StationPacking List:
1× bga rework station
5× nozzles: 4 pcs top(19,29,34,37mm) and 1 pcs bottom(50mm);
6× pcb jig (with screw)
1x vacuum pen
1× k-type thermocouple
1x socket head wrench
1x Computer Cable
1× CD of manual and software (if not get, may be lost in customs, please contact us)
