LY OMEGA XD universal bga soldering rework station 3 zones hot air & Infrared 5500W
Technical Parameters
| Basic Parameters |
||
| Heating |
IR and HR |
|
| Dimension |
L550mmx W550mmx H500mm |
|
| Weight |
45kg |
|
| Total weight |
About 70 kg, vary with the differen need of the users |
|
| Electrical Parameters |
||
| Power |
220V AC |
|
| Upper Heating |
IR and HR |
|
| Size of upper (IR) |
80*80mm |
|
| Consumption of upper (IR) |
300W (ELSTEIN heating plate SHTS/4) | |
| Nozzle of upper(HR) |
4 pcs: 15x15, 31x31, 38x38, 45x45mm |
|
| Consumption of upper (HR) |
800W |
|
| Bottom Heating |
HR |
|
| Nozzle of bottom(HR) |
1 pcs 58x58mm |
|
| Consumption of bottom (HR) |
800W |
|
| Bottom Preheat |
IR |
|
| Consumption of preheat (IR) |
4600W |
|
| General power |
5.5KW |
|
| Temperature Control |
||
| Control mode of Upper |
Independent temperature control, high-precision closed-loop |
|
| Control mode of Bottom |
Independent temperature control, high-precision closed-loop |
|
| Rework Function |
||
| SMD |
Suit for welding, remove or repair packaged devices |
|
| Size of applicable chips |
≤80mm x80 mm |
|
| Size of applicable PCB |
≤450mm x350mm |
|
Packing list:
1× bga rework station (with IR Top and Hot air Top)
2× pcb bottom support
6× pcb jig (with screw)
5× nozzles (4 pcs for top 1 pcs for bottom)
2× k-type Omega thermocouple
1× brush
1× CD of manual and software (if not get, may be lost in customs, please contact us)
