Description AC220V two/three way fan coil electric motorized valve



Product's detials:

Valve body:Brass CW617N(Europe standard)            Seal Material: nitrile rubber (NBR) Stem:Brass CW617N(Europe standard) Drive chassis: flame retardant ABS engineering plastics Drive cover: flame retardant glass fiber reinforced PA engineering plastic Drive power : AC220V (+10%, 15%)(or12V,24V,110V), 50Hz power consumption ≤ 5W Can bear pressure (MPa) : 2.5MPa Body connection : standard cylindrical pipe thread Applicable medium : chilled water, hot water or low pressure steam Applicable liquid temperature : 2 ° C ~ 105 ° C Ambient temperature and humidity : 0 ° C ~ 50 ° C no condensation Water flow control mode : on/off Motor category : Hysteresis synchronous motor, speed 500r/min Full travel time : 6 seconds on, off 4 seconds

Application：

VC6013/4013-BAB series electric valve is used to control the opening or closing of central air conditioning system and heating system pipeline to achieve the purpose of controlling room temperature. The control valve is driven by a one-way hysteresis synchronous motor with a spring return. When the valve is not working, it is in the normally closed state. When it needs to work, the temperature controller provides a valve opening signal to make the electric valve act on the AC power source, open the valve, and chilled water or hot water enters the fan coil to provide the room. Cold air or heating; when the room temperature reaches the set value of the thermostat, the thermostat de-energizes the electric valve, and the return spring closes the valve, thereby cutting off the flow of water into the fan coil. By closing and opening the valve, the room temperature is always maintained within the temperature range set by the thermostat.

VC6013/4013-BAB series electric valve can be equipped with auxiliary switch, which can be applied to the control of other equipments; different connection forms and applicable voltages can be selected to meet different needs.

VC6013/4013-BAB series electric valve, flexible operation, reliable and durable, low working noise, and can withstand high temperature and high humidity environment in concealed fan coil unit



Wiring diagram and schematic diagram：



Note::::

Please note your control type and voltage,thank you!
