free shipping to moscow or almaty , 80w CO2 laser engraving machine 1290/1390 with AWC708S contoller



Technical Parameters

Laser power :	80-90w(optional)
Laser tube life Span	3000 working/hours.
Applicable Materials	Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc.
Working area:	1200*900 mm
Max moving speed:	1500mm/s
Laser energy control:	1-100℅ set by hand or software
Worktable:	Electric up and down table/Honeycomb table/Aluminum table(optional)
Locating precision:	<0.01 mm
Min shaping character:	Character: 3*3 mm,; letter: 2*2 mm
Operating temperature:	5℃-35℃
Resolution ratio:	≦4500 dpi
Laser type:	Hermetic CO2 glass tube
Power supply:	AC220±10℅50 HZ/AC110±10℅50 HZ
Control configuration:	DSP.
Data transfer interface:	USB (offline).
USB Ports	2
System environment:	WINDOWS 7/WINDOWS XP/MAC/Vista
Cooling way:	Water cooling and protection system
Graphic format supported:	The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG, DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX).
USER MENU	Full English.
Package Inclusion	Software,VIDEO USER MENU CD,Air pump gun,Power cables, USB cables, Water tank,Water Pipe,Smoke Vent-pipe,Air Blow Pipe ,exhaust fan,Tools bag
Memory	64 MB
Display screen	LCD(SIZE 70*40 mm)
Protection System	Yes
Option parts	high-grade cooling system/double-head/cylinder rotary Jig/ irregular rotary Jig/ up&down table/ knifes table
Guarantee	1 year ,damageable spare parts(like laser tube,mirrors)  3 months
Dimensions	1880*1300*1120mm
Dimensions(package)	1980*1430*1300 mm
Net Weight	370KGs
Gross Weight	420KGs
Recommended Ship way	Sea

Machine picrtures --- Laser head and working table

Advantage：

AWC708S or RD6442s contoller

*Carving precision, cutting and engraving can be carried out at the same time. *You can power off continued carving, and Can repeat engraving. *More durable and more stable







-- step motor

-- Control box



-- Smoke  flue



--switch and plug









Applicable Materials Plastic,acrylic, jade, crystal, rubber,leather, organic glass and other non-metal materials.   Applicable Industry Mainly used for the engraving and cutting of little artistic works. Such as engraved portraits, badges, breast cards and various engraved packages. It can also engrave seals and crabs.
