Low Cost High Speed 40Kpps Galvo Galvometter Laser Light Galvometer Animation Laser Scanners Head For Stage Lamp DJ Laser Show
Product Specifications :
Product name: 40K laser scanner
Model: ALYCZ-40B
Scanning speed: 40Kpps (ILDA standard test pattern)
Scanning angle: 40°
Mirror size:7x12x0.8mm
Motor diameter:10.3mm
Mirror type: High quality dielectric mirrors reflectivity >98% at 400nm-700nm (RGB system application); High reflectivity single color dielectric mirrors reflectivity >99% at 532nm ( high power green system application)
Analog signal input impedance: 100K ± 1% Ω (single-ended input)
Analog position input range: ±10 V
Working temperature: 0~50°C
Power requirements: AC 85-285V 50-60Hz output ±24V 2A
Warranty: 2 years
Packing List :
1pcs 40K galvo scanner (X Y motors with mount)
1pcs DC24V power supply
2pcs driver board
4pcs connect cable
Optional Parts :
If you want to DIY your laser light or upgrade your laser projector system, the below parts is good choice ! More technical support, please contact us!
1. Scanfail board is optional
2. DMX board is optional
3. ILDA board is optional
4. Multifunctional ILDA&DMX Control Board is optional
5. LCD display is optional
6. SD memory function is optional
Scanning Angle:

Potentiometer function: Offset: Electrical offset of the driver, not the galvo ! Is adjusted in factory. HFD: High Frequency Damping. Corrects undershoots LFD: Low Frequency Damping Corrects overshoots. Servo: Servo-Gain. Power of the feedback signal for the internal PID controller. Size: Increases or decreases input sensitivity of the complete driver.  Does not change driver settings. Position Scale: factory setting. Lineartity: factory setting Warning !  1,Tune Galvo Scanner only by the professionals!If you want to tune your galvo scanner, please contact me,  I will send you the document!  2,The product will be constantly improved and upgraded,different batches of products may be different in appearance,the pictures is only for your reference. If any discrepancy found between the picture and actual product, the actual product shall prevail,hope to get your understand and support!

We also provide OEM and ODM service ! Any questions or concerns, please contact us.
