Motor Governor LED Dimmer 10V-50V 15A Motor Speed Regulator Controller Switch

Features:

1 high frequency 20 kHz

2 signal pure

3 PWM 1% ~ 100%

4 support high current 15A

5 high quality knob

6 knob support switch function

7 metal oxide semiconductor diode protection

8 The signal is stable.

9 It is not affected by the start and stop of the motor.

Three parameters:

1 Product Name: ZK-GZT PWM DC Motor Speed Controller

2 Quantity: ZK-GZT*1

3 Working voltage: DC 10.0 v - 50.0 v

4 Output current: 0 ~ 15

5 Output power: 300 w (Max)

6 standby current: 7 ua

7 PWM duty cycle: 1% ~ 100%

8 pulse width modulation frequency: 20 khz

9 Operating temperature range: -20 ° C ~ 85 ° C

10 Operating humidity range: 0% - -95% rh

11 Mounting hole diameter: 2 mm

12 dimensions: 77 * 32 * 25 mm

4. Steps for use: 1, Stop rotating the potentiometer counterclockwise until the sound of the potentiometer is heard. It is used to turn off the output. 2 Connect a DC motor or LED to the output. 3 Connect the right input voltage to the input terminals. 4 Adjust the potentiometer to adjust the motor speed or LED brightness.

Five. Note:1 It is a DC motor governor. You cannot enter ac or the module will be damaged. 2 The power supply can't be reversed. Otherwise the module will be damaged. 3 The drive section is separable from the adjustment section. 4 Please read the instruction manual and manual before use.

Six. Application:1 motor speed control 2 Adjust the brightness of the lamp 3 robot control 4 smart car control 5 toys 6 smart home

7. Packing list:1 1pcs ZK-GZT PWM DC motor speed controller; 2 1pcs 40cm XH2.54-5P female to female cable;
